Atlas Copco OSC 170 CLAY Compressed Air Water Separator

The Atlas Copco OSC 170 CLAY Compressed Air Water Separator is a high-capacity, dual-stage condensate treatment solution designed to efficiently remove oil from compressed air condensate streams. Rated for up to 451 CFM (compressor only) or 360 CFM when combined with a dryer, the OSC 170 CLAY uses a specialized organoclay filtration media that excels at handling synthetic oil emulsions, providing superior oil removal compared to standard activated carbon.

Engineered for compliance and convenience, the unit reduces oil discharge levels to as low as 5 ppm, helping your facility meet EPA and local environmental regulations. Maintenance is simple thanks to quick-change filter bags, a service indicator for saturation, and a long 4,000-hour filter life. A test outlet is included to verify filtration performance, and an overflow indicator ensures safe operation.

The OSC 170 CLAY is ideal for demanding environments where synthetic lubricants are used and higher-performance oil separation is required.

Key Features:

• Handles up to 451 CFM (360 CFM w/ dryer)

• Organo clay media targets strong synthetic oil emulsions

• Dual-stage filtration (polypropylene + organoclay)

• Discharge oil content as low as 5 ppm

• Service life up to 4,000 hours

• Easy maintenance with quick-change filters

• Service & overflow indicators for operational safety

• Test outlet to verify separator performance

• Compact, rugged design for industrial environments

Perfect For:

Manufacturing plants, industrial facilities, and automotive operations using synthetic compressor oils who require high-efficiency oil removal and environmental compliance for their compressed air condensate discharge.
